Design and Preparation of fire drawing
Fire Safety Drawing and System Design in Odisha
We prepare fire-protection drawings and coordinated layouts for proposed and existing buildings in Bhubaneswar and across Odisha. The drawing scope is developed from available architectural plans, building use, site conditions, system requirements and the purpose for which the documents are needed.
Fire drawing services
- Review of architectural plans and project information
- Hydrant, sprinkler and pump-house layouts
- Fire detection, alarm and notification layouts
- Equipment locations, escape routes and safety signage
- BOQ support and revisions within the agreed scope
Information needed to begin
Clients should provide current floor plans, sections, site information, occupancy details and available fire-system requirements. A survey may be required when reliable as-built information is not available. Any submission or approval process remains subject to the relevant authority and project requirements.
Frequently Asked Questions
Can drawings be prepared for an existing building?
Yes, subject to receiving usable plans and completing any survey needed to confirm existing conditions and installed systems.
Is BOQ preparation available with the drawings?
Yes. BOQ and budgetary support can be included when the required systems and level of detail are agreed.
